EPLUS

AlumiCore™ chassis with aluminum frame eliminates rusting and corrosion, extending the Villager 4’s lifespan significantly.

SportDrive allows the Villager 4 to handle like an automobile making it easier to maneuver and more fun to drive.

Specially-designed
ergonomic seats provide back support while a contoured seat bottom
guarantees the most comfortable ride anywhere.

Power Source	Gas
Engine	Kawasaki 4-cycle, OHV, 351 cc, single-cylinder, air-cooled, pressure-lubricated, spin-on oil filter
Horsepower	11.5 hp @ 3,600 rpm, exceeds SAE J1940 Performance Standards
Steering	Self-adjusting rack and pinion
Front Suspension	Mono-leaf springs with dual hydraulic shocks
Seating Capacity	4
Ground Clearance	4.5 in (11.4 cm)
Fuel Tank Capacity	7 gal (26L)
Speed Range	12-15 mph (19.3-24.1 kph)
Brakes	Rear-wheel, mechanical drum
Park Brake	Foot-operated, multi-lock
Frame Chassis	Aluminum box beam with composite cross member
Body	Formion®
Body color	Molded-in color
Front tires	18 x 8.50-8, 4-ply rated, premium tread
Rear tires	18 x 8.50-8, 4-ply rated, premium tread
Overall Length	104 in (264.2 cm)
Overall Width	47.3 in (120.1 cm)
Overall Height	68.5 in (174 cn)
Wheelbase	65.5 in (166.4 cm)
Tread	34.5 in/38.6 in (87.6 cm/97.8 cm)
Dry Weight (Less Batteries)	640 lb (290 kg)
Vehicle Warranty	2-year limited
Electrical System	12-volt, 500 CCA 85 min reserve
Rear Suspension	Mono-leaf springs with dual hydraulic shocks
Instrumentation	Electronic fuel gauge/hour meter, low-oil warning light
Total Vehicle Capacity	800 lb (362.9 kg)
Turning Radius	8.4 ft (2.6 m)
Governor	Automatic ground speed sensing
Governed RPM	2875 +/- 30
Drive Unit	Unitized transaxle, helical gears: 11.8:1 forward, 17.1:1 reverse
Outside Radius Circle	17.3 ft (5.3 m)
Intersecting Aisle Radius	6 ft (1.8 m)
Stabilizer Bar	No
