EPLUS

Industry\'s Best 2-year Limited Warranty

Club Car\'s exclusive IQ Plus System™ 48-volt electric motor

Carries up to 4 passengers

AlumiCore™ chassis with aluminum frame eliminates rusting and corrosion, extending the Villager 4’s lifespan significantly.

SportDrive allows the Villager 4 to handle like an automobile making it easier to maneuver and more fun to drive.

Impact and UV resistant body panels with 360 degree bumper system

Specially-designed ergonomic seats provide back support while a contoured seat bottom guarantees the most comfortable ride anywhere.

Dual dash compartments and quad cupholders

Wheel covers standard

Maximum Speed of 15 mph (24.1 kph)

Battery warning light standard

Power Source	Electric
Horsepower	3.3 hp @ 3,050 rpm (continuous), 11 hp @ 1,800 rpm (intermittent)
Batteries	(6) 8-volt batteries
Charger	Automatic 48-volt DC, 17 amp, UL and CUL listed
Steering	Self-adjusting rack and pinion
Front Suspension	Mono-leaf springs with dual hydraulic shocks
Seating Capacity	4
Ground Clearance	4.5 in (11.4 cm)
Speed Range	8-19 mph (12.9-30.6 kph)
Brakes	Rear-wheel, mechanical drum
Park Brake	Foot-operated, multi-lock
Frame Chassis	Aluminum box beam with composite cross member
Body	Formion®
Body color	Molded-in color
Front tires	18 x 8.50-8, 4-ply rated, premium tread
Rear tires	18 x 8.50-8, 4-ply rated, premium tread
Overall Length	104 in (264.2 cm)
Overall Width	47.3 in (120.1 cm)
Overall Height	68.5 in (174 cn)
Wheelbase	65.5 in (166.4 cm)
Tread	34.5 in/38.6 in (87.6 cm/97.8 cm)
Dry Weight (Less Batteries)	735 lb (333 kg)
Vehicle Warranty	2-year, limited; 4-year batteries; 4-year limited battery warranty
Electrical System	48-volt
Rear Suspension	Mono-leaf springs with dual hydraulic shocks
Instrumentation	Battery capacity indicator, Battery warning light
Total Vehicle Capacity	800 lb (362.9 kg)
Turning Radius	8.4 ft (2.6 m)
Drive Motor	48-volt shunt/sepex
Drive Unit	12.3:1 direct-drive axle, double-reduction helical gear
Controller	250A solid state
Outside Radius Circle	Circle 17.3 ft (5.3 m)
Intersecting Aisle Radius	6 ft (1.8 m)
