Carryall 700 Gas Utility Vehicle
With more cargo space than any other Carryall, the Carryall 6 is the ultimate tool for
heavy hauling, featuring 1,500 pounds of capacity, a nearly six-foot long cargo bed,
and 17.1 cubic feet of cargo space that can be customized to suit your needs.
|
| |
|
|
|
|
| |
|
- Independent front suspension with self-adjusting rack and pinion steering
- Industry\'s Best 2-year Limited Warranty
- Maximum speed of 16 mph (25.7 kph)
- Rustproof Aircraft Grade Aluminum Frame, Chassis & optional Cargo Box
- ArmorFlex® Front Body for fade-resistant color
- Heavy Duty Front Bumper
- Ergonomic dash mounted shifter and dual storage pockets.
- Side fuel fill
- 1,500 lb. (681 kg) Total Vehicle Capacity
- Large Cargo Bed Capacity, nearly 6 ft. (179.1 cm) long
- 351 cc gasoline 11.5 hp engine
- Electronic fuel gauge/hour meter, low-oil warning light
- Headlights, tail lights, brake lights, and horn
Power Source |
Gas |
Engine |
Kawasaki 4-cycle, OHV, 351 cc, single-cylinder, air-cooled, pressure-lubricated, spin-on oil filter |
Horsepower |
11.5 hp @ 3,600 rpm, exceeds SAE J1940 Performance Standards |
Steering |
Self-adjusting rack and pinion |
Front Suspension |
Independent leaf spring with dual hydraulic shocks |
Seating Capacity |
2 |
Ground Clearance |
4.5 in (11.4 cm) |
Fuel Tank Capacity |
6 gallons (22.7 L) |
Speed Range |
14-16 mph (22.5-25.7 kph) |
Brakes |
4-wheel mechanical drum |
Park Brake |
Foot-operated, multi-lock |
Frame Chassis |
Aluminum I-beam |
Body color |
Matching paint over molded in color |
Front tires |
18 x 6.50-8, 6-ply rated, premium tread |
Rear tires |
18 x 6.50-8, 6-ply rated, premium tread |
Overall Length |
134 in (340.4 cm) |
Overall Width |
49.3 in (125.2 cm) |
Overall Height |
48 in (121.9 cm) |
Wheelbase |
98.5 in (250.2 cm) |
Tread |
34.5 in/38.5 in (87.6 cm/97.8 cm) |
Dry Weight (Less Batteries) |
868 lb (394.1 kg) |
Vehicle Warranty |
2-year limited |
Ignition |
Electronic with electronic limiter |
Electrical System |
12-volt, 500 cca 105 min reserve |
Rear Suspension |
Leaf springs with dual hydraulic shocks |
Front Body |
ArmorFlex® |
Bed Height |
27 in (68.6 cm) |
Bed Capacity |
1,000 lb (499.4 kg) |
Cargo Bed Size |
70.5 in x 45.1 in x 9.3 in (17.1 ft3) 179.1 cm x 114.6 cm x 23.5 cm |
Instrumentation |
Battery capacity indicator, Battery warning light |
Total Vehicle Capacity |
1,500 lb (681 kg) |
Turning Radius |
12 ft (3.7 m) |
Governor |
Automatic ground speed sensing, internally geared-in unitized transaxle |
Governed RPM |
3050 +/- 30 |
Drive Unit |
Unitized transaxle with helical gears: 11.8:1 forward, 17.1:1 reverse |
Rear Body |
All aluminum |
Flat Bed Size |
67.6 in x 44.2 in (171.8 cm x 112.2 cm) |
Outside Radius Circle |
24.7 ft (7.5 m) dia |
Intersecting Aisle Radius |
90 in (228.6 cm) |
Stabilizer Bar |
Yes |
Light Package |
Standard |
|
| |
|
|
|
|
|
