Carryall 700 Electric Utility Vehicle
With more cargo space than any other Carryall, the Carryall 6 is the ultimate tool for
heavy hauling, featuring 1,500 pounds of capacity, a nearly six-foot long cargo bed,
and 17.1 cubic feet of cargo space that can be customized to suit your needs.
*Electric version features Club Car\'s exclusive IQ Plus System™.
|
| |
|
|
|
|
| |
|
- Independent front suspension with self-adjusting rack and pinion steering
- Industry\'s Best 2-year Limited Warranty
- Club Car\'s exclusive IQ Plus System™ 48-volt electric motor
- Rustproof Aircraft Grade Aluminum Frame, Chassis & optional Cargo Box
- The Club Car IQ Plus System™ delivers a 48-volt platform and advanced drive train technology. IQ Plus System™ provides best-in-class programmable speed between 8 and 17 mph, superior energy management, usable range and service capabilities.
- ArmorFlex® Front Body for fade-resistant color
- Heavy Duty Front Bumper
- Ergonomic dash mounted shifter and dual storage pockets.
- Maximum speed of 17 mph (27.4 kph)
- 1,500 lb. (681 kg) Total Vehicle Capacity
- Large Cargo Bed Capacity, nearly 6 ft. (179.1 cm) long
- Headlights, tail lights, brake lights, and horn
- Battery capacity indicator, battery warning light
- Optional SmartKey tm for dual maximum speeds
Power Source |
Electric |
Horsepower |
3.7 hp @ 3,400 rpm (continuous) 21 hp @ 2,000 rpm (peak) |
Batteries |
Eight 6-volt, Standard: 115 min. @ 75amps; Heavy Duty: 145 minutes @ 75 amps |
Charger |
On-board with reel, automatic, computer-controlled 48-volt DC, 17 amp, UL and CUL listed |
Steering |
Self-adjusting rack and pinion |
Front Suspension |
Independent leaf spring with dual hydraulic shocks |
Seating Capacity |
2 |
Ground Clearance |
4.5 in (11.4 cm) |
Speed Range |
5-17 mph (8-27.3 kph) |
Brakes |
4-wheel mechanical drum |
Park Brake |
Foot-operated, multi-lock |
Frame Chassis |
Aluminum I-beam |
Body color |
Matching paint over molded in color |
Front tires |
18 x 6.50-8, 6-ply rated, premium tread |
Rear tires |
18 x 6.50-8, 6-ply rated, premium tread |
Overall Length |
134 in (340.4 cm) |
Overall Width |
49.3 in (125.2 cm) |
Overall Height |
48 in (121.9 cm) |
Wheelbase |
98.5 in (250.2 cm) |
Tread |
34.5 in/38.5 in (87.6 cm/97.8 cm) |
Dry Weight (Less Batteries) |
743 lb (337.3 kg) |
Vehicle Warranty |
2-year limited, 4-year limited battery warranty |
Electrical System |
48-volt |
Rear Suspension |
Leaf springs with dual hydraulic shocks |
Front Body |
ArmorFlex® |
Bed Height |
27 in (68.6 cm) |
Bed Capacity |
1,000 lb (499.4 kg) |
Cargo Bed Size |
70.5 in x 45.1 in x 9.3 in (17.1 ft3) 179.1 cm x 114.6 cm x 23.5 cm |
Instrumentation |
Battery capacity indicator, Battery warning light |
Total Vehicle Capacity |
1,500 lb (681 kg) |
Turning Radius |
12 ft (3.7 m) |
Drive Motor |
48-volt shunt/sepex |
Drive Unit |
12.3:1 direct-drive axle, double-reduction helical gear |
Controller |
500 amp solid state |
Rear Body |
All aluminum |
Flat Bed Size |
67.6 in x 44.2 in (171.8 cm x 112.2 cm) |
Outside Radius Circle |
24.7 ft (7.5 m) dia |
Intersecting Aisle Radius |
90 in (228.6 cm) |
Stabilizer Bar |
No |
Light Package |
Standard |
|
| |
|
|
|
|
|
