Power Source |
Electric |
Horsepower |
3.7 hp @ 3,400 rpm (continuous) 21 hp @ 2,000 rpm (peak) |
Batteries |
Eight 6-volt, Standard: 115 min @ 75 amps; Heavy Duty: 145 min @ 75 amps |
Charger |
Automatic, computer-controlled 48-volt DC, 17 amp, UL and CUL listed |
Steering |
Self-adjusting rack and pinion |
Front Suspension |
Independent leaf spring with dual hydraulic shocks |
Seating Capacity |
2 |
Ground Clearance |
4.5 in (11.4 cm) |
Speed Range |
5-17 mph (8-27.3 kph) |
Brakes |
4-wheel |
Park Brake |
Foot-operated, multi-lock |
Frame Chassis |
Aluminum I-beam |
Body color |
Matching paint over molded in color |
Front tires |
18 x 8.50-8, 6 ply rated, premium tread |
Rear tires |
18 x 8.50-8, 6 ply rated, premium tread |
Overall Length |
111 in (281.9 cm) |
Overall Width |
50 in (127 cm) |
Overall Height |
48 in (121.9 cm) |
Wheelbase |
77.5 in (196.9 cm) |
Tread |
34.5 in/38.5 in (87.6 cm/97.8 cm) |
Dry Weight (Less Batteries) |
767 lb (347.9 kg) |
Vehicle Warranty |
2-year limited, 4-year limited battery warranty |
Electrical System |
48-volt |
Rear Suspension |
Leaf springs with dual hydraulic shocks |
Front Body |
ArmorFlex® |
Bed Height |
27.5 in (69.9 cm) |
Bed Capacity |
800 lb (363.2 kg) |
Cargo Bed Size |
48.8 in x 49.8 in x 10.9 in (15.3 ft3) 123.8 cm x 126.4 cm x 27.6 cm |
Instrumentation |
Battery warning light |
Total Vehicle Capacity |
1,200 lb (544.8 kg) |
Turning Radius |
10 ft (3 m) |
Drive Motor |
48-volt shunt/sepex |
Drive Unit |
12.3:1 direct-drive axle, double-reduction helical gear |
Controller |
500 amp solid state |
Key or Pedal Start |
Pedal |
Rear Body |
All aluminum |
Flat Bed Size |
46.9 in x 48.3 in (119.1 cm x 122.7 cm) |
Outside Radius Circle |
20.7 ft (6.3 m) dia |
Intersecting Aisle Radius |
77 in (195.6 cm) |
Stabilizer Bar |
No |
