Power Source |
Electric |
Horsepower |
3.2 hp @ 2,400 rpm (continuous). 10 hp @ 1,125 rpm (intermittent) |
Batteries |
Six 8-volt 117 min. @ 56 amp |
Charger |
Automatic 48-volt DC, 17 amp, UL and CUL listed |
Steering |
Self-adjusting rack and pinion |
Front Suspension |
Independent leaf spring with dual hydraulic shocks |
Seating Capacity |
2 |
Speed Range |
8-19 mph (12.8-24.1 kph) |
Brakes |
Leaf springs with dual hydraulic shocks |
Park Brake |
Foot-operated, multi-lock |
Frame Chassis |
Aluminum I-beam |
Body color |
Matching paint over molded in color |
Front tires |
18 x 8.50-8, 4 ply rated, premium tread |
Rear tires |
18 x 8.50-8, 4 ply rated, premium tread |
Overall Length |
103.5 in (262.9 cm) |
Overall Width |
48 in (121.9 cm) |
Overall Height |
48 in (121.9 cm) |
Wheelbase |
65.5 in (166.4 cm) |
Tread |
34.5 in/38.5 in (87.6 cm/97.8 cm) |
Dry Weight (Less Batteries) |
530 lb (240.6 kg) |
Vehicle Warranty |
2-year limited, 4-year limited battery warranty |
Electrical System |
48-volt |
Rear Suspension |
Leaf springs with dual hydraulic shocks |
Front Body |
ArmorFlex® |
Bed Height |
27.5 in (69.9 cm) |
Bed Capacity |
300 lb (136.1 kg) |
Cargo Bed Size |
37.6 in x 45.1 in x 9.3 in (9.1 ft3) 95.6 cm x 114.6 cm x 23.5 cm |
Instrumentation |
Battery warning light |
Total Vehicle Capacity |
800 lb (363.2 kg) |
Turning Radius |
8.4 ft (2.6 m) |
Drive Motor |
48-volt shunt/sepex |
Drive Unit |
12.3:1 direct-drive axle, double-reduction helical gear |
Controller |
250 amp solid state |
Rear Body |
All aluminum |
Flat Bed Size |
35.8 in x 44.3 in (90.8 cm x 112.4 cm) |
Outside Radius Circle |
17.5 ft (5.3 m) dia |
Intersecting Aisle Radius |
72 in (182.9 cm) |
Stabilizer Bar |
No |
