EPLUS

The Club Car IQ Plus System™ delivers a 48-volt platform and advanced drive train technology. IQ Plus System™ provides best-in-class programmable speed between 8 and 17 mph, superior energy management, usable range and service capabilities.

Power Source	Electric
Horsepower	3.7 hp @ 4,097rpm (continuous) 21 hp @ 1,663 rpm (intermittent)
Batteries	Eight 6-volt, Standard: 115 min. @ 75amps; Heavy Duty: 145 minutes @ 75 amps
Charger	Automatic, computer-controlled 48-volt DC, 17 amp, UL and CUL listed
Steering	Self-adjusting rack and pinion
Front Suspension	Independent leaf spring with dual hydraulic shocks
Seating Capacity	8
Ground Clearance	4.5 in (11.4 cm)
Speed Range	5-17 mph (8-27.3 kph)
Brakes	4-wheel mechanical drum
Park Brake	Foot-operated, multi-lock
Frame Chassis	Aluminum I-beam
Body	ArmorFlex®
Body color	Matching paint over molded in color
Front tires	18 x 6.50-8, 6-ply rated, premium tread
Rear tires	18 x 6.50-8, 6-ply rated, premium tread
Overall Length	157 in (398.8 cm)
Overall Width	47.3 in (120.1 cm)
Overall Height	48 in (121.9 cm)
Wheelbase	131.5 in (334 cm)
Tread	34.5 in/38.6 in (87.6 cm/97.8 cm)
Dry Weight (Less Batteries)	704 lb (319.6 kg)
Vehicle Warranty	2-year, limited; 4-year batteries; 4-year limited battery warranty
Electrical System	48-volt
Rear Suspension	Leaf springs with dual hydraulic shocks
Instrumentation	Battery capacity indicator, Battery warning light
Total Vehicle Capacity	1,500 lb (681 kg)
Turning Radius	15.9 ft (4.8 m)
Drive Motor	48-volt shunt-wound
Drive Unit	12.3:1 direct-drive axle, double-reduction helical gear
Controller	500A solid state
Outside Radius Circle	32.6 ft (9.9 m) dia
Intersecting Aisle Radius	9 ft (274.3 cm)
Stabilizer Bar	No
Light Package	Standard
