Power Source |
Electric |
Horsepower |
3.3 hp @ 3,050 rpm (continuous), 11 hp @ 1,800 rpm (intermittent) |
Batteries |
(6) 8-volt batteries |
Charger |
Automatic 48-volt DC, 17 amp, UL and CUL listed |
Steering |
Self-adjusting rack and pinion |
Front Suspension |
Mono-leaf springs with dual hydraulic shocks |
Seating Capacity |
4 |
Ground Clearance |
4.5 in (11.4 cm) |
Speed Range |
8-19 mph (12.9-30.6 kph) |
Brakes |
Rear-wheel, mechanical drum |
Park Brake |
Foot-operated, multi-lock |
Frame Chassis |
Aluminum box beam with composite cross member |
Body |
Formion® |
Body color |
Molded-in color |
Front tires |
18 x 8.50-8, 4-ply rated, premium tread |
Rear tires |
18 x 8.50-8, 4-ply rated, premium tread |
Overall Length |
104 in (264.2 cm) |
Overall Width |
47.3 in (120.1 cm) |
Overall Height |
68.5 in (174 cn) |
Wheelbase |
65.5 in (166.4 cm) |
Tread |
34.5 in/38.6 in (87.6 cm/97.8 cm) |
Dry Weight (Less Batteries) |
735 lb (333 kg) |
Vehicle Warranty |
2-year, limited; 4-year batteries; 4-year limited battery warranty |
Electrical System |
48-volt |
Rear Suspension |
Mono-leaf springs with dual hydraulic shocks |
Instrumentation |
Battery capacity indicator, Battery warning light |
Total Vehicle Capacity |
800 lb (362.9 kg) |
Turning Radius |
8.4 ft (2.6 m) |
Drive Motor |
48-volt shunt/sepex |
Drive Unit |
12.3:1 direct-drive axle, double-reduction helical gear |
Controller |
250A solid state |
Outside Radius Circle |
Circle 17.3 ft (5.3 m) |
Intersecting Aisle Radius |
6 ft (1.8 m) |
