Engine |
480cc Vanguard® HSE 4-stroke, air-cooled V-twin cylinder |
Horsepower |
14.0 hp (10.4 kw) |
Steering |
Rack & pinion |
Front Suspension |
MacPherson strut/ 5.1 in |
Seating Capacity |
2 |
Ground Clearance |
9.0 in (22.8 cm) |
Fuel Tank Capacity |
5.2 gal (19.6 L) |
Brakes |
4-wheel, hydraulic disc |
Park Brake |
Hand-operated |
Frame Chassis |
Box tube steel |
Front tires |
All Terrain 25 x 9-12 4-ply, (optional mud tires available) |
Rear tires |
All Terrain 25 x 9-12 4-ply, (optional mud tires available) |
Overall Length |
105 in (266.7 cm) |
Overall Width |
55 in (139.7 cm) |
Overall Height |
73 in (185.4 cm) |
Wheelbase |
71 in (180.3 cm) |
Tread |
48.8 in (124 cm)/ 48.8 in (124 cm) |
Dry Weight (Less Batteries) |
1,335 lb (605.5 kg) |
Vehicle Warranty |
2-year/2,000-hour, limited |
Engine - Cooling |
Air |
Engine - Lubrication and Oil Filter Type |
Full-pressure; spin-on |
Maximum torque |
22.9 ft-lbs |
Ignition |
Fixed Magneto |
4WD Engagement |
Shift on Demand 4WD |
Front Differential |
Open |
Rear Differential |
Locking |
High-Low Range Engagement |
Automatic |
Torque Converter |
CVT |
Electrical System |
12-volt, 500 CCA |
Rear Suspension |
Independent rear trailing arm suspension/ 5.2 in travel |
Bed Height |
33.5 in (85.1 cm) |
Bed Capacity |
400 lb (181.4 kg) |
Cargo Bed Size |
34 x 47 x 10 in (86.3 x 119.4 x 25.4 cm) |
Instrumentation |
Electronic fuel gauge/hour meter, low oil warning light (speedometer optional) |
Total Vehicle Capacity |
925 lb (419.5 kg) |
Seating |
Bench |
Turning Radius |
10.9 ft (3.3 m) |
Key or Pedal Start |
Key |
Rear Body |
Rugged, scratch-resistant, injection-molded plastic |
Light Package |
Halogen headlamps with available turn signals and fog lamps |
Differential Lock |
Manual Differential Lock |
Cup Holders |
2 |
